About Piezo Motor Company
Company Profile
Piezo Motor Company is a U.S.-based innovator in miniature motion control technology, specializing in ultracompact rotary and linear piezoelectric motors. Developed by a team of leading scientists and engineers, Piezo Motors' patented solutions offer exceptional precision, responsiveness, and reliability, making them ideal for cutting-edge applications where traditional motors fall short.
Unlike conventional electromagnetic motors, piezoelectric motors use vibration-driven ceramic resonators to create movement. This design delivers high-resolution positioning, no electromagnetic interference, silent operation, and instant braking without energy draw, setting a new standard for motion control in demanding environments.
Power Supply Voltage 7.5 V DC
Stall Torque >= 4 mNm
Self-Braking Torque >= 5 mNm
Actuator Response Time < 30 με
Max Speed > 600 rpm
Minimum Angular Step 30 urad
Angular Backlash 30 prad
Angular Hysteresis 30 urad
Frequency Response 4 kHz
Operating Temperature - 20 deg * C to 80 deg * C
Maximum Axial Load 200 g
Maximum Radial Load 200 g
Moment of Inertia 29.2gm * m ^ 2
Max Current over velocity range 300 mA
Rotor Runout <= 50mu*m
Actuator Weight 6.3 g
Actuator Dimensions (no shaft) 13 * 19 * 9.1mm
Driver PCB Dimensions 28 * 31 * 9.6mm
Driver PCB Weight 6.8 g
Power Supply Voltage 5.0 V DC
Push/Pull Force >= 0.2N
Self-Braking Force >= 0.25N
Motor Response Time < 30 με
Travel Range 9.0 mm
Max Speed (continuous mode) >= 200mm/s
Minimum Linear Step <0.04 µm
Linear Backlash at Change of Direction <0.1 µm
Elastic Stiffness < 200mN / mu * m
Linear Hysteresis <2.0 µm
Pitch* <1 mrad
Maximum Moment Mx* 0.07 Nm
Roll* <0.5 mrad
Maximum Moment My* 0.12 Nm
Yaw* <1 mrad
Maximum Moment Mz* 0.9 Nm
Vertical Runout* 3.0 µm
Horizontal Runout* 6.0 µm
Frequency Response 4 kHz
Operating Temperature - 20°C to 80 °C
Maximum Load (at listed specification) 20 g
Maximum Tolerable Load 4.2 kgf
Max Current (continuous mode) 300 mA
Max. Current at the velocity 10mm/s (PWM mode) 30-40 mA
Motor Weight 4.7 g
Motor Dimensions 16.3 * 16.5 * 5.7mm
Driver PCB Dimensions 31 * 28 * 9.6mm
Drive PCB Weight 20 g
